1-1/2″ Female Quick Coupler x 1-1/2″ Male Thread w/ Locking Cam Levers (L150B)
Banjo Poly Locking Cam Lever Couplings
1-1/2″ Female Quick Coupler x 1-1/2″ Male Thread
Max PSI: 125
Gasket: EPDM
Features
Stainless steel rings, arms & pins
Most complete line of polypropylene couplings available
Versatile – interchangeable with all types of cam lever couplers
Precision molded – insures a uniform and accurate fit
Durable – Polypropylene is glass filled for rugged strength and durability
Smooth operating – finger rings are designed for easy opening of cam levers
Complete series of 1/2″, 3/4″, 1″, 1 1/4″, 1 1/2″, 2″, 3″ and 4″ NPT thread
BSP threads available 1″ – 3″ sizes (excluding 1 1/4)
Operating conditions:
3/8″ thru 2″ – 100 P.S.I. at 0°F; 125 P.S.I. at 70°F; 70 P.S.I. at 150°F.
2 1/2″, 3″ & 4″ Cap – 50 P.S.I.; Couplings 75 P.S.I. max
Economical and superior in performance
Standard with EPDM gaskets. Buna, and FKM (viton) also available
Banjo Part Number:
L150B – 1-1/2″ Female Quick Coupler x 1-1/2″ Male Thread w/ Locking Cam Levers (L150B)
